HVAC Aromatherapy System for 5000 Cubic Meters Coverage with 1000ml
Oil Bottle
Introduction of HVAC Aromatherapy System
| Storage Design | There is a storage inside the machine, we could put all the spare
parts and user manual into it so that no need to find it everywhere
when you need it. |
| Packing Way | Regarding to the packing, we use eco-friendly polybag, foam and 3
layers inner box, and then put it into the 5 layers master carton.
It will be much safer in transportation and friendlier. |
| Coverage | Up to a maximum 5000 cubic meters |
| Technology | CH123 HVAC Aromatherapy System creates the dry therapeutic scent
mist by using the cold air diffusion technology without using the
heat, without water or adding other additive. The cold air
diffusion technology nebulizes the essential oils or fragrance oils
into a nanoparticle, dry scent mist, allowing for fully absorbed by
every corner and no traces no residue left behind in the air. |
| Essential oil consumption | CH123 fragrance system is with 1000ml oil capacity bottle and with
low oil consumption. There is total 19 levels intensity. If use
CHARM AROMA essential oils and working time user set 8 hours one
day, and the intensity we set 95% ( the highest one ), total
essential oil consumption is 49.4ml per day, so 1000ml one bottle
oil could use (1000 divided by 49.4) 20 days. It is so convenient
so that no need to refill the essential oil all the time. |
Specification
| Model No. | CH123 HVAC Aromatherapy System |
| Shell Material | Anticorrosion Metal |
| Color | White , Black |
| Dimension | 390H X 270W X 185D mm |
| Net Weight | 7.5kg |
| Standard Packing | 4 Pieces / Master Carton |
| Power Supply | 110-220V/ 26W |
| Coverage | 3000-5000m3 |
| Installation Way | Connect HVAC /Wall Mounted / Standalone |
| Essential Oil Bottle Capacity | 1000ml in Aluminum |
| Essential Oil Consumption | 0.33ml ~ 6.2 ml /H (+/-5%) |
| Noise Level | < 50dba |
| Atomizer Material | Aluminum alloy |
| Origin | Made in China |
| Technology | Cold air diffusion technology |
| Warranty | 12 months |
Advantage
1, no heating via nanoparticle atomizing technology
2, no trace no residue of the scent mist in the air
3, Connect to HVAC system, wall mounted and stand-alone, multiple
installation ways
4, Low noise, less than 50DB
5, With PCB to control the working time, stopping time and the
scent intensity level
6, Easy maintenance and operation
7, Aluminum alloy atomizer, durable than the plastic one
8, Metal body material
9, 1000ml big capacity of the essential oil bottle in aluminum
material
10, up to 5000 cubic meters coverage
11, lockable to protect the essential oil and the LCD
12, Storage room for the spare part and the user manual
Usefulness
- Destroy the heavy smoking bad odor, food odors, attacks the various
odors from the pets and help to destroy unpleasant smells in such
an environment, reduce bad smelling of solid surfaces near toilets
or urinals and more.
- So that to leave a good impression for all your clients, makes good
moods and a cleaner and fresher environment for all of us, let all
of us feel healthier and more pleasant. Your clients and your staff
will have all these advantage.
