    26W Scent Diffuser Machine 5000 Cubic Meters Adjustable Scent Intensity

    Ask Lasest Price
    Brand Name : CharmAroma
    Model Number : CH123
    Certification : CE and more
    Price : negotiation
    Payment Terms : T/T, Paypal and more
    Supply Ability : 1000 Pieces per Month
    Delivery Time : Within 5-15 Working Days
    • Product Details
    • Company Profile

    26W Scent Diffuser Machine 5000 Cubic Meters Adjustable Scent Intensity


    26W Electronic Odor Neutralizing System for the Air Conditioning System with Aluminum Oils Bottle


    Introduction Electronic Odor Neutralizing System


    Cold-Air Nebulizing TechnologyThe CH123 scent system using the cold-air nebulizing technology that is without heat so that to keep the maximum benefits of the essential oils, and spread the dry and fine scent mist into the air without any oily residue behind.
    FunctionCH123 is the Electronic Odor Neutralizing System which could encourage repeating visits, increase the customers’ visiting time and enhance the sales and more. The CH123 scent deliver system freshens indoor areas of up to a maximum 5000 cubic meters, and is ideal for controlled scenting of the hotels and motels, beauty parlors, apartments, hospitals, daycares, kindergartens and schools, office buildings and factories, department stores, pet areas & stores, public washrooms, conference rooms, restaurants, nursing homes and more.
    Other Advantage
    • Coverage up to 5000 cubic meters
    • HVAC type, Multi-mounting and stand-alone options
    • Lock and key of the door designed
    • Optional timer and adjustable scent intensity
    • 12 months’ free warranty
    • Metal body made in China
    • 1000ml aluminum essential oil bottle
    Storage DesignThere is a storage space inside the machine, we could put the spare parts and the user manual, and then lock the door to protect them.

    Technical Data


    Model No.CH123 Electronic Odor Neutralizing System
    Shell MaterialAnticorrosion Metal
    ColorWhite , Black
    Dimension390H X 270W X 185D mm
    Net Weight7.5kg
    Standard Packing4 Pieces / Master Carton
    Power Supply110-220V/ 26W
    Coverage3000-5000m3
    Installation WayConnect HVAC /Wall Mounted / Standalone
    Essential Oil Bottle Capacity1000ml in Aluminum
    Essential Oil Consumption0.33ml ~ 6.2 ml /H(+/-5%)
    Noise Level< 50dba
    Atomizer MaterialAluminum alloy
    OriginMade in China
    TechnologyCold air diffusion technology

    Aroma Marketing


    1. The scent marketing becomes the more and more popular for the all commercial places. It is a trending advertising way for the marketing strategy.
    2. Scent marketing has several types included thematic smell, ambient smells, aroma billboard smell, signature smell. The thematic smell complements the decor or purpose of the place; the ambient smells could cover unpleasant odors or to “fill a void”; the aroma billboard smell, the customers are consciously aware of it; the signature smell used to create a brand image.
    3. The scent marketing threats the unidentified odor and the highly subjective.
    4. The scent marketing is making by the below specifications included geography, ages, genders and the culture of the target market.
    5. The key usage of the scent marketing is diffusing the essential oils, making the natural environment, simply to make it done.
    6. The benefits of the scent marketing are to boost sales, to make all the customers linger, to create brand image and perception of quality.

    Operation Steps


    Pease read CH123 user manual or see our video demo for the first time using.

    Step 1use the key to open the machine door
    Step 2Fill maximum 1000ml essential oil into the empty oil bottle and put it back into the scent machine
    Step 3

    connect the air tube with the HVAC system and the scent machine

    Tips of connect to HVAC system

    • Confirm the position of the machine as shown as below photo.
    • Connect the air tube into the HVAC system. The hole of the tube must be higher than the scent machine, and the direction of tube should be downwind.
    • After confirming the position of the tube, punch the hole and fix the air tube in the hole with a tie wrap.
    Step 4Plug the diffuser to electric socket
    Step 5Press the 4 keys to set the local time same as your country
    Step 6Press the 4 keys to set the working time and the intensity
    Step 7Lock back the scent machine door. Done, please enjoy your scenting world.
