Aluminum Alloy Atomizer Head up to 5000cbm HVAC Aroma Scent Machine

Aroma Scent Machine Introduction

The atomizer head of CH123 aroma scent machine is made by aluminum alloy so that the life of it is longer than the plastic one. Thanks for the powerful air pump; the coverage of CH123 could up to 5000 m3. This scent machine could be directly connected with the existing HVAC system to deliver the dry essential oil mist to every room which is linked to the HVAC system. Beside to connect to the air conditioning system, it also could wall mounted and stand-alone if you need.

This kind of scent diffuser is working by the cold air diffusion technology that without any heat to protect the essential oil benefit and there is no trace of the dry scent mist in the air. This is the biggest difference with other scent diffuser.

It is easy to install and operate this scent machine since we already well install it well; if using it as a standalone model, there is no need any installation; if using it as the wall mounted type, just use the screw and the screw connector to fix the wall mounted panel on the wall; if using it as the HVAC type, here is the tips for connecting the air tube with the HVAC system.

• Confirm the position of the machine as shown as below photo.
• Connect the air tube into the HVAC system. The hole of the tube must be higher than the scent machine, and the direction of tube should be downwind.
• After confirming the position of the tube, punch the hole and fix the air tube in the hole with a tie wrap.

Technical Data

Strong Point

1, no heating via nanoparticle atomizing technology

2, no trace no residue of the scent mist

3, Connect to HVAC system, wall mounted and stand-alone, multiple installation ways

4, Low noise

5, With PCB to control the working time, stopping time and the scent intensity level

6, Easy maintenance and operation

7, aluminum alloy atomizer

8, Metal body material

9, 1000ml big capacity of the essential oil bottle in aluminum material

10, up to 5000 cubic meters coverage

11, lockable to protect the essential oil and the LCD

12, Storage room for the spare part and the user manual

Product Maintenance

In the below cases, please do the maintenance same as our instruction.

• If don't use the scent machine for a long time, please clean the machine after final use.
• Every one- two months clean one time.
• Before change to another flavor of the essential oil
• Cleaning steps as below:

1. Pour out the essential oil from the oil bottle
2. Fill the 95% alcohol into the empty bottle
3. Set the strongest intensity means 95%, and then turn on the machine to work for 10-15 minutes,
4. Turn off it and finally pour away the alcohol.
5. Done
